15 ft Power Cord - Right-Angle NEMA 5-15P to C13 - Computer Power Cord - C13 Power Cord - Right Angle Power Cord - Connect your computer / monitor / printer to a wall outlet without blocking other outlets - Rated to carry 125V at 10A - 18 AWG - Right-angle plug positions the connector so that it sits off to the side of the wall outlet and frees up the second outlet for another cord - Lifetime warranty - PXTR101 / PXTR10115 / Computer Power Cord / C13 Power Cord / Right Angle Po
  • Cost: $44.15
  • Quantity: 1
  • Free Shipping
  • Views:
  • Sold and Shipped By: eforgo
General InformationThis 3-foot vertical cable manager gives you a simple and space-efficient way to organize the cables in your server rack. You can attach the cable manager vertically into your rack, to neatly guide cables between equipment that's mounted at different heights.The 0U cable manager offers versatile installation options and is compatible with most racks that are 20U or larger. The panel features a 0U design that doesn't take up any mounting space, and with simple tool-less installation, it's easy to attach or reposition as necessary.Improve the appearance and accessibility of your rackThe vertical cable manager uses a finger-duct method of cable management, which includes a cover panel that neatly conceals the cables that are running through it. The cable manager runs vertically along the side of your rack, to neatly guide cables between equipment that's mounted at different heights. This provides a tidy and well-organized way to run cables from devices mounted toward the bottom of your rack to other devices mounted near the top, without leaving a mess of cables hanging in between.Having neatly organized and routed cables not only improves the appearance and accessibility of your rack, it also makes it easier for you to install, access and maintain rack components. Hassle-free compatibility with your rackFor maximum compatibility with virtually any server rack, you can install the cable-management panel using mounting holes that are commonly found on most rack equipment. The tool-less mounting method attaches the cable management panel to the keyhole-shaped mounting holes that are built into your rack. The horizontal mounting rail method attaches the cable management panel to the horizontal mounting rails that run along the side of your rack. For racks that don't support these installation methods, you can also mount the cable management panel through other means, such as using the non-standardized holes found on your rack walls and enclosures, or the rack units on equipment mounting rails.Protect your equipmentRouting your cables through a panel reduces the tension that's often put on cables. This prevents cable damage or connection loss, and reduces strain on equipment ports, preventing damage to your expensive rack-mounted devices.Properly routing cables also improves airflow, which passively cools devices stored in your rack, helping to keep your equipment running at optimal temperatures to reduce the probability of damage caused by your rack overheating.The CMVER20UF is backed by a StarTech.com 2-year warranty and free lifetime technical support. Physical CharacteristicsColor: BlackMaterial: SteelMaterial: PlasticRack Height: 20UHeight: 2.9"Width: 33.6"Length: 3.9"Weight (Approximate): 5 lbMiscellaneousPackage Contents: Vertical Cable Organizer with Finger Ducts - 0U - 3 ft. 4 x M5 Cage Nuts 4 x M5 Cage Screws 2 x M4 Nuts 1 x Instruction Manual Environmentally Friendly: YesEnvironmental Certification: RoHSEnvironmental Certification: REACHWarrantyLimited Warranty: 2 Year
General Information
Manufacturer:StarTech.com
Manufacturer Part Number:MSTDP124DP
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:MST hub - DisplayPort to 4x DisplayPort
Marketing Information:

This MST hub lets you connect four monitors to your DisplayPort™ (DP) 1.2 equipped Windows® laptop or desktop.

Increase productivity with multiple screens

The newest generations of computers are more portable than ever, which often means that you're left with fewer video outputs and smaller integrated screens. ThisMST hubsolves both of these problems by letting you connect four additional displays to your computer, which makes multitasking much easier.

Connect to any display

With the MST hub, you can use DisplayPort video adapters and cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. This MST hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.

Configure your displays for any environment

Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display giving you the freedom to multitask and increase your productivity. You can also mirror the same image onto multiple displaysfor remote viewing applications such as digital signage.

Enjoy amazing video quality, without draining system resources

MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming and medical imaging.

Note: When using a DisplayPort 1.1 video card the MST hub will act as a splitter, automatically mirroring your video source across all displays. Resolution limitations apply.

The MSTDP124DP supports plug-and-play installation for a hassle-free setup, and is backed by a StarTech.com 3-year warranty and free lifetime technical support.

Note: MST shares 21.6Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.Certain graphics adapters have limited MST support and will only output to three displays in total. If more than three monitors are attached the fourth will be disabled.

Average resolution bandwidth allocation:

1920x1080 (High-definition 1080p) @60hz - 22% 1920x1200 @60hz - 30% 2560x1440 @60hz - 35% 2560x1600 @60hz - 38% 3840 x 2160 (Ultra HD 4K) @30hz - 38%

Note: Exceeding 100% will reduce functionality.

Examples of supported resolution configurations:

Screen 1 Resolution

Screen 2 Resolution

Screen 3 Resolution

Screen 4 Resolution

Total % of Bandwidth

1920x1080 @60hz (22%) 1920x1080 @60hz (22%) 1920x1080 @60hz (22%) 1920x1080 @60hz (22%) 88% 1920x1200 @60hz (30%) 1920x1080 @60hz (22%) 1920x1080 @60hz (22%) 1920x1080 @60hz (22%) 96% 3840x2160 @30hz (38%) 1920x1080 @60hz (22%) 1920x1080 @60hz (22%) off 82% 3840x2160 @30hz (38%) 1920x1200 @30hz (30%) 1920x1080 @60hz (22%) off 90% Examples of unsupported resolution configurations Screen 1 Resolution Screen 2 Resolution Screen 3 Resolution Screen 4 Resolution Total % of Bandwidth 2560x1600 @60hz (38%) 2560x1600 @60hz (38%) 1920x1200 @60hz (30%) 1920x1200 @60hz (30%) 136% 3840x2160 @30hz (38%) 2560x1600 @60hz (38%) 1920x1200 @60hz (30%) 1920x1200 @60hz (30%) 136% 3840x2160 @30hz (38%) 2560x1600 @60hz (38%) 2560x1440 @60hz (35%) 1920x1200 @60hz (30%) 141% 3840x2160 @30hz (38%) 3840x2160 @30hz (38%) 3840x2160 @30hz (38%) off 114%


Packaged Quantity:1
Product Type:Signal Splitter

Video
Maximum Video Resolution:3840 r 2160
Interfaces/Ports
DisplayPort:Yes
Number of DisplayPort Inputs:1
Number of DisplayPort Outputs:4
Media & Performance
Maximum Operating Distance:78.74"
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC

Physical Characteristics
Product Color:Black
Product Material:Plastic
Height:0.6"
Width:2.6"
Length:15.2"
Weight (Approximate):4.55 oz
Miscellaneous
Package Contents:
  • MST hub - DisplayPort to 4x DisplayPort
  • 1 x Universal Power Adapter (NA/EU/UK/AUS)
  • 1 x Quick Install Guide

Additional Information:Hardware
  • Audio Yes
  • Chipset ID STDP4320
  • Converter Type MST Hub
  • Output Signal DisplayPort
  • Ports 4
Performance
  • Maximum Digital Resolutions 3840 x 2160 @30hz
  • Supported Resolutions 1024x768
  • 1280x720 (High-definition 720p)
  • 1920x1080 (High-definition 1080p)
  • 1920x1200
  • 2560x1440
  • 2560x1600
  • 3840 x 2160 (Ultra HD 4K) @30hz
  • Wide Screen Supported Yes
Environmental
  • Operating Temperature 0°C to 45°C (32°F to 113°F)
  • Storage Temperature -20°C to 70°C (-4°F to 158°F)

Environmentally Friendly:Yes
Environmental Certification:
  • RoHS
  • WEEE
  • REACH

Country of Origin:China
Warranty
Limited Warranty:3 Year
