The Tripp Lite SRW12US33 SmartRack 12U Server Depth Wallmount Rack Enclosure Cabinet is designed to house EIA-standard 19 in. rack equipment in network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 250 lbs. The doors and side panels lock securely to help prevent damage, tampering or theft. The front, top, bottom and removable side panels are vented, which allows air to flow freely and keep equipment cool. The reversible doors can open left or right by rotating the cabinet 180° before mounting. Convenient top and bottom ports allow easy cable routing. The SRW12US33 comes fully assembled and ready to mount to the wall, or use Tripp Lite’s optional SRCASTER rolling caster kit to make it a mobile rack.
Ideal for network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space Secures 12U of 19 in. rack equipment up to 32.5 in. deep Maximum load capacity of 250 lbs. Swings away from wall on hinge for easy, backdoor access to equipment and cabling during installation and maintenance Cabinet should be rotated 180° before mounting to open reversible doors left or right Locking steel cabinet vented at sides, front, top and bottom Flow-through ventilation keeps equipment cool Convenient ports with removable covers allow cable routing through top and bottom Wall-mounting holes spaced 16 in. apart for standard wall stud placement Vertical mounting rails adjust in 7/8 in. increments to accommodate equipment up to 32.5 in. deep, such as network switches and patch panels Rails support square hole or 12-24 threaded-hole mounting Rack spaces numbered for easy reference Can be converted to a roll rack with optional SRCASTER (sold separately) Meets Payment Card Industry Standards Ships fully assembled 5-year limited warranty Includes 36 M6 screws, 36 M6 cage nuts, 36 M6 washers, 36 12-24 screws and 2 keys
