Tripp Lite's B040-008-19 KVM Switch gives you a rack-mountable keyboard, LCD and touchpad in a single console that occupies only 1U of rack space. Easy to install and use, it's the cost-effective solution for controlling up to eight directly connected computers/servers. The B040-008-19 has a built-in 19-inch LCD screen that supports video resolutions up to 1366 x 768. You can switch easily between the eight ports using on-console push buttons, an on-screen display (OSD) or keyboard hot key commands. Password protection prohibits unauthorized users from accessing the connected computers.
OVERVIEW
Port Control
Push Buttons, Hotkeys, OSD Max CPU
248 PHYSICAL
Color
Black Style
1U Rackmount Console LCD Monitor (in.)
19 CONNECTIONS
Ports
8 Computer/Server Ports
(x8) HD15 Female Daisy-Chain Port
HD15 Female Firmware Upgrade Port
HD15 Male Other Ports
USB A Female (for external keyboard/mouse attachment ) CERTIFICATIONS
Approvals
TUV (UL), CTUV, CE, FCC, NOM, RoHS Item Dimension (L"xW"xH")
34.5 x 23 x 6 Weight
45 Warranty
1 Year
