General Information
Manufacturer:Tripp Lite
Manufacturer Part Number:AVR900U
Manufacturer Website Address:http://www.tripplite.com
Brand Name:Tripp Lite
Product Series:AVR
Product Name:AVR 900VA Desktop UPS
Marketing Information:
AVR Series Line-Interactive UPS System offers ultra-compact, line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space saving right-angle input plug, six battery/surge-protected outlets and six additional surge-only outlets (12 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.
Packaged Quantity:1 Each
Product Type:Line-interactive UPS
Technical Information
AVR:Yes
AVR Range:Boost +18% / Buck -15%
Plug/Connector Type:NEMA 5-15P
Receptacle Type:NEMA 5-15R
Receptacle Detail:12 x NEMA 5-15R
Number of Battery & Surge Outlets:6
Number of Surge-only Outlets:6
Transfer Time:6 ms
EMI/RFI Noise Filter:Yes
Phase:Single Phase
Power Description
Load Capacity:900 VA/480 W
Input Voltage:120 V AC
Output Voltage:
Input Frequency:60 Hz
Output Frequency:60 Hz
Waveform Type:Pulse-width Modulated Sine Wave
Surge Energy Rating:316 J
Management
Alarm:
- Battery Backup
- Low Battery
- Fault
- Overload
- Replace Battery
Controls/Indicators
Status Indicators:
2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions
Interfaces/Ports
USB:Yes
USB (HID Compliant) Port:Yes
Battery Information
DC System Voltage:12 V DC
Battery Chemistry:Sealed Lead Acid (SLA)
Backup/Run Time (Full Load):2.70 Minute
Backup/Run Time (Half Load):10 Minute
Typical Battery Recharge Time:8 Hour
Replaceable Battery:Yes
Environmental Conditions
Maximum Operating Temperature:104°F (40°C)
Storage Temperature:5°F (-15°C) - 113°F (45°C)
Physical Characteristics
Height:4.1"
Width:7.5"
Depth:12"
Form Factor:Ultra-compact Desktop/Tower/Wall Mount
Weight (Approximate):16.50 lb
Miscellaneous
Package Contents:
- AVR 900VA Desktop UPS
- Owner's manual
Additional Information:
- Appearance: All black ultra-compact housing
Output voltage regulation:
- Sine wave 120V +14% / -12% (line mode)
- PWM sine wave 115V +/-5% (battery mode)
Output frequency regulation:
- Line Mode: Passes line frequency of 60Hz +/-10%
- Battery Mode: Inverter output regulated to 60Hz +/-0.5Hz
Certifications & Standards:
UL Listed Certification
Software Included:PowerAlert Software
Assembly Required:No
Environmentally Friendly:Yes
Environmental Certification:RoHS
Country of Origin:United States
Warranty
Limited Warranty:3 Year
Additional Warranty Information:
2 year warranty
- 100,000 Connected equipment guarantee
